Legend Valve 101-300NL

T-1001NL Forged Brass Full-Port Ball Valve, 1/8 in, FNPT, Lead-Free

  • Manufacturers: Legend Valve
  • Brand Name: Legend Valve
  • PN: 101-300NL
  • MPN: 101-300NL
  • UPC: 662545081885
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Ball Material      :      Forged Brass
Connection Size      :      1/8 in
Connection Type      :      FNPT
Dimension      :      1.54 in L
Item Name      :      Ball Valve
Material Specifications      :      ASTM A510, UNS G10060, CW510L, UNS C28500
Material      :      Forged Brass
Model      :      T-1001NL
Operator Type      :      Dacromet Coated Steel Handle
Pressure Rating      :      150 psi Saturated Steam, 600 psi CWP Non-Shock
Seat Material      :      TFM PTFE
Stem Material      :      Forged Brass
Type      :      Full-Port
  • Lead-free design is suitable for all no-lead potable water installations in full compliance of all lead-free plumbing laws
  • Bottom loaded blowout-proof stem
  • Maintenance-free dual O-ring stem seal
  • Improved Dyneon TFM PTFE seats
  • Dacromet coated steel, tamper-evident hand wheel nut, TFM PTFE anti-friction washer and thrust washer, (2) fluorocarbon stem O-rings, forged brass end adapter, dacromet coated steel locking device

Standards/Certifications: US federal public law 111-380, ANSI/NSF 61-G, ANSI/ASME B1.20.1, cCSAus, ISO 9002 standard, FM approved
