American Valve M100S.112

M100S Forged Brass 2-Piece Full-Port Ball Valve, 1-1/2 in, Solder

  • Manufacturers: American Valve
  • Brand Name: American Valve
  • PN: M100S.112
  • MPN: M100S.112
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Ball Material      :      Brass/Forged Brass
Connection Size      :      1-1/2 in
Connection Type      :      Solder
Dimension      :      4-3/8 in L x 4-3/8 in H
Flow Co-Efficient      :      207 Cv
Item Name      :      Ball Valve
Material Specifications      :      ASTM B16
Material      :      Forged Brass
Model      :      M100S
Operator Type      :      Steel Handle
Packaging Material      :      PTFE
Pressure Rating      :      150 psi WSP, 600 psi WOG
Seal Material      :      PTFE
Seat Material      :      PTFE
Stem Material      :      Brass
Temperature Rating      :      365 deg F
Type      :      Full-Port, 2-Piece
  • Blow-out proof stem
  • PTFE adjustable packing
  • Positive shut-off
  • For use in most process applications

Standards/Certifications: IAPMO/ANSI Z1157, Massachusetts plumbing board approved

Applications: For fire protection applications
