Worcestor 1 4416-TSE

44 Brass 3-Piece Floating Ball Valve, 1 in, FNPT

  • Manufacturers: Flowserve Corporation
  • Brand Name: Worcestor
  • PN: .WORBR1
  • MPN: 1 4416-TSE
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Ball Material      :      316 Stainless Steel
Connection Size      :      1 in
Connection Type      :      FNPT
Dimension      :      3.66 in L x 2.38 in W
Flow Co-Efficient      :      32 Cv
Item Name      :      Floating Ball Valve
Material Specifications      :      ASTM B283 Grade C3770, ASTM A479
Material      :      Brass
Operator Type      :      Lever Handle
Pressure Rating      :      1500 psi
Seal Material      :      TFE
Series      :      44
Stem Material      :      316 Stainless Steel
Temperature Rating      :      -50 to 600 deg F
Type      :      3-Piece

Flowserve Worcester Controls series 44 3-piece ball valves, for many years the most respected ball valve design in the industry, are now better than ever. A major research, design, and testing program brings you a new valve, designed to ANSI B16.34 specifications with advanced seal technology and body mount bracket design.

  • Special build configurations to meet customers application
  • Bubble tight shut-off with bi-directional flow provides process flexibility
  • Low operating torques allowing for compact actuator operation reducing space and cost requirements
  • Fast, easy and inexpensive maintenance facilitated by compact, slip-out body design with seat and body seal accessibility
  • High-performance
  • Body mounted actuator design
  • Swing-out design for easy maintenance
  • Tight shut-off and bidirectional sealing
  • Screwed pipe ends

Standards/Certifications: UL, YRBX, YRPV, YSDT, YQAR, YQNZ, VQGU listed, USCG, USDA, FM approved, NACE MRO I-75, ANSI B16.11, ANSI B1.20.1, MSS SP-25 certified
