Trion 255649-101

Air Bear MERV 8 Media Air Filter, 16 x 25 x 3 in

  • Manufacturers: Trion
  • Brand Name: Trion
  • PN: TR255649-101
  • MPN: 255649-101
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Actual Size      :      24-1/4 in W x 15-3/4 in H x 3.06 in D
Depth      :      3 in
Frame Type      :      Moisture-Resistant
Height      :      25 in
Item Name      :      Media Air Filter
MERV      :      8
Sub Brand      :      Air Bear
Width      :      16 in

Mechanical MERV 8 filter maintains efficiency under all operating conditions.

  • Finger supported vertical pleats remain evenly spaced while maximizing dirt holding capacity at the lowest pressure drop
  • Suitable for use with all types of forced-air HVAC configurations
  • Factory-installed, double gasket, top and bottom, eliminates filter bypass
  • Galvanized rust-resistant wire mesh, integral width filter media, supports media and retains pleat shape even when dirty
  • Moisture-resistant frame retains strength and shape even in high humidity

Standards/Certifications: UL 900 listed

Applications: Fits Generalaire
