AGF AGF1000.1.38

TESTanDRAIN 1000 Bronze Sectional Floor Control Test and Drain Valve with 3/8 in Orifice, 1 in, NPT

  • Manufacturers: AGF Manufacturing
  • Brand Name: AGF
  • PN: AGF1000.1.38
  • MPN: AGF1000.1.38
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Ball Material      :      Chrome-Plated Brass
Connection Size      :      1 in
Connection Type      :      NPT
Dimension      :      5-1/16 in L x 6-3/8 in H
Item Name      :      Sectional Floor Control Test and Drain Valve with 3/8 in Orifice
Material      :      Bronze
Model      :      1000
Pressure Rating      :      300 psi
Seat Material      :      Impregnated Teflon
Stem Material      :      Rod Brass
Sub Brand      :      TESTanDRAIN

The lightweight and compact model 1000 is a 300 psi rated 1-handle ball valve designed to provide both the test and express drain functions required for a wet fire sprinkler system. The model 1000 inspector test and drain valve eliminates the multiple connections required by the traditional assembly loop saving time, space and money.

  • Compact, 1-handle ball valve
  • Tamper-resistant test orifice and sight glasses
  • Tapped and plugged port for system access
  • Repair kits including (1) adapter gasket, (1) ball, (2) valve seats, (1) stem packing and (1) stem washer
  • Reliability, versatility, code compatibility
  • Steel handle, indicator plate and handle stop
  • Made in USA

Standards/Certifications: UL and ULC listed, NYC-BSA No. 720-87-SM, NFPA-13, NFPA-13R and NFPA-13D, FM approved

Applications: For wet fire sprinkler systems

  • pdf Catalog https://www.plumbers-supply-co.com//ASSETS/DOCUMENTS/ITEMS/EN/UNI-PS11945_Cat.pdf
  • pdf Installation Sheet https://www.plumbers-supply-co.com//ASSETS/DOCUMENTS/ITEMS/EN/UNI-PS11945_Instal.pdf
  • pdf Specification Sheet https://www.plumbers-supply-co.com//ASSETS/DOCUMENTS/ITEMS/EN/UNI-PS11945_Spec.pdf
