SharkBite 23000-0045

EB-75 Iron Compact Pressure Regulating Valve, 3/4 in, FNPT, 45 psi Factory Setting

  • Manufacturers: Reliance Worldwide Corporation
  • Brand Name: SharkBite
  • PN: 23000-0045
  • MPN: 23000-0045
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Connection Size      :      3/4 in
Connection Type      :      FNPT
Dimension      :      3-49/64 in L x 5.39 in H
Item Name      :      Pressure Regulating Valve
Material      :      Iron
Model      :      EB-75
Pressure Rating      :      45 psi Factory Setting
Seat Material      :      Polysulphone
Temperature Rating      :      180 deg F
Type      :      Compact

The Cash Acme EB-75 is a compact, iron-body pressure reducing and regulating valve designed for installations where small size and economy are important, and where local codes allow the use of iron body regulators for water service. This regulator is intended for use where supply line inlet pressure does not exceed 300 psi. The EB75 is suitable for either cold or hot (to 180 deg F) water service. This valve automatically reduces and regulates inlet pressures down to the standard factory setting of 45 psi.

  • In built back-pass check - allows water to flow back through the regulator in cases of thermal expansion caused by hot water heating devices
  • Every valve is tested for performance prior to shipping
  • Fully pressure-balanced piston
  • Assembled and tested in the USA
  • Iron spring chamber, reinforced EPDM diaphragm, steel adjusting spring

Applications: For non-potable industrial water system application
