Liberty Pumps 404L
Powder Coated Aluminum Compact Low Profile Automatic Drain Pump, 115 V, 1/3 hp, 3450 rpm, 38 gpm, 21 ft
- Manufacturers: Liberty Pumps
- Brand Name: Liberty Pumps
- PN: 404L
- MPN: 404L
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
| Amperage Rating | : | 5.2 A Full Load, 8 A Locked Rotor |
| Bearing Type | : | Ball |
| Connection Size | : | 2 in |
| Cord Length | : | 10 ft |
| Dimension | : | 13.7 in W x 11.3 in H |
| Finish | : | Powder Coated |
| Flow Rate | : | 38 gpm |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/3 hp |
| Impeller Material | : | Polymer |
| Item Name | : | Drain Pump |
| Material | : | Aluminum |
| Maximum Feet of Head | : | 21 ft |
| Phase | : | 1 ph |
| RPM | : | 3450 rpm |
| Temperature Rating | : | 140 deg F |
| Type | : | Compact, Low Profile, Automatic |
| Voltage Rating | : | 115 V |
The short profile of Liberty's 404 is specially designed for compact areas and gives you the freedom to install fixtures where gravity drain lines are not available. QuickTree technology provides a separate access cover for easy switch inspection. For gray wastewater applications, the 404 is perfect for laundry tray sinks, bar sinks, washing machines and other basement remodeling projects. The system arrives fully assembled and ready to install.
- Compact design for tight areas
- Factory pre-assembled
- Fully automatic operation
- QuickTree technology allows quick inspection and removal of float switch without disconnecting the plumbing
- Integrally molded rubber gaskets for a superior gas-tight seal
- Oil-filled, hermetically-sealed motor with thermal overload protection
- 10 ft 3-wire power cord with grounded plug
- Corrosion-resistant polyolefin basin with molded in connections
- Maintenance-free, permanently lubricated sealed bearings
- 3/8 in solids handling
- 4.3 gal basin capacity
- 2 in discharge and vent
- Class B stator winding
- 3-years warranty
Standards/Certifications: cCSAus, SSPMA certified
Applications: For bar sinks, laundry trays, dehumidifiers, utility sinks and gray wastewater drainage below gravity lines
