BrassCraft R1700RX R1
Brass Dual Outlet, Multi-Turn Supply Stop Valve with Window Tray, 1/2 x 3/8 in, Nominal CPVC x Compression, Rough Brass
- Manufacturers: Brasscraft Manufacturing
- Brand Name: BrassCraft
- PN: R1700RX R1
- MPN: R1700RX R1
- UPC: 026613135847
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
| Connection Size | : | 1/2 x 3/8 in |
| Connection Type | : | Nominal CPVC x Compression |
| Dimension | : | 2.49 in L |
| Finish | : | Rough Brass |
| Handle Type | : | Oval-Knurled |
| Item Name | : | Supply Stop Valve with Window Tray |
| Material | : | Brass |
| Operator Type | : | ABS/Polycarbonate Handle |
| Pressure Rating | : | 125 psi |
| Temperature Rating | : | 40 - 140 deg F |
| Type | : | Dual Outlet, Multi-Turn |
BrassCraft 3/8 in FIP inlet x 3/8 in OD compression x 1/4 in OD compression (right side) dual outlet multi-turn valve controls water flow to household plumbing fixtures. The dual outlet allows two independent supply lines to be attached to a single valve. Ideal for adding dishwashers, ice makers, water filters and instant hot water dispensers to existing water supply. With a few turns of the valve handle, you are able to stop the flow of water leading to the plumbing fixture, allowing for maintenance and repair without shutting off the water to the entire home.
- Machined 1-piece brass body provides strength, durability and long-lasting performance
- Knurled oval handle provides a secure grip and smooth on/off operation
- Easy-to-remove handle with screw attachment protects accidental stop operation during rough-ins
- Rubber bib and packing washers, brass packing nut, zinc-plated steel screw, brass compression sleeve, plated brass compression nut
Standards/Certifications: ASME A112.18.1/CSA B125.1, ANSI/NSF 61 and 372 certified, IAPMO, UPC listed
Applications: For potable water distribution systems
