Lochinvar
Knight High Efficiency Residential Fire Tube Boiler, 4.9 gal, 120 VAC, 1 ph
- Manufacturers: A. O. Smith Corporation
- Brand Name: Lochinvar
- PN: WHB199N
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
Oversized
| AFUE | : | 95% |
| Amperage Rating | : | 3.3 A |
| BTU Rating | : | 199999 Btu/hr Input, 18999 - 189999 Btu/hr Output |
| Capacity | : | 4.9 gal |
| Connection Size | : | 1/2 in Gas, 1-1/4 in Water, 3 in Air Inlet |
| Dimension | : | 25 in W x 35-1/2 in H x 21-3/4 in D |
| Frequency Rating | : | 60 Hz |
| Item Name | : | Fire Tube Boiler |
| Mounting | : | Wall Hung |
| Phase | : | 1 ph |
| Pressure Rating | : | 80 psi |
| Sub Brand | : | Knight |
| Type | : | Residential, High-Efficiency |
| Vent Size | : | 3 in |
| Voltage Rating | : | 120 VAC |
- Knight fire tube wall mount boiler gives greater installation flexibility with the performance you've come to expect
- Smart system digital operating control
- 3-boiler set-point temperature inputs
- Built-in cascading sequencer for up to 8 boilers, with cascade redundancy
- Outdoor reset control with outdoor air sensor
- Programmable system efficiency optimizers
- 4-pump control
- Domestic hot water prioritization
- Building management system integration
- Access to building management system settings through graphic LCD display
- Low, high-voltage terminal strip
- Time clock, data logging
- Maintenance reminder
- Low-water flow safety control and indication
- Password security
- Customizable freeze protection parameters
- 95% DOE AFUE efficiency
- Modulating burner with up to 10:1 turn-down
- Direct spark ignition
- Low NOx compliant
- ASME stainless steel heat exchanger
- Vertical and horizontal direct vent
- Universal vent adapter
- ECM variable-speed boiler circulating pump
- 110 V convenience outlet
- Automatic reset high limit
- Adjustable high limit with manual reset
- Zero clearances to combustible materials
- 15-years limited warranty and 5-years limited parts warranty
Standards/Certifications: Energy star, AHRI certified, ASME H stamped, CSA design certified
