F1RES49 Chrome-Plated Quick Response Pendent Sprinkler, 1/2 in NPT, 155 deg F, 4.9 K-Factor

  • Manufacturers: Reliable Automatic Sprinkler
  • Brand Name: Reliable
  • PN: 49CN
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Connection Type      :      NPT
Dimension      :      1-1/4 in L x 2-1/4 in H
Finish      :      Chrome-Plated
Item Name      :      Pendent Sprinkler
K-Factor      :      4.9
Model      :      F1RES49
Nominal Size      :      1/2 in
Pressure Rating      :      175 psi
Series      :      F1Res
Temperature Rating      :      155 deg F
Type      :      Quick Response

Model F1Res series sprinklers are residential sprinklers with a 3 mm glass bulb operating element. A variety of K-factors as well as recessed and conical concealed options are available. The F1Res series sprinklers are specially engineered for fast thermal response to meet the requirements of UL 1626. They are intended for installation in accordance with NFPA 13, 13R and 13D.

  • 3 mm glass bulb thermal sensor
  • Brass alloy sprinkler frame
  • Copper alloy button
  • Nickel alloy with PTFE sealing assembly
  • Bronze alloy load screw, deflector

Standards/Certifications: cULus listed
