Gastite XR3-OUTLETBOX-8

FlashShield XR3 Series Stainless Steel Outlet Box, 1/2 in

  • Manufacturers: Gastite
  • Brand Name: Gastite
  • PN: XR3OUTLETBOX-8
  • MPN: XR3-OUTLETBOX-8
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Connection Size      :      1/2 in
Item Name      :      Outlet Box
Material      :      Stainless Steel
Pressure Rating      :      25 psi
Series      :      XR3
Sub Brand      :      FlashShield
Temperature Rating      :      -40 to 160 deg F

FlashShield is metallically shielded corrugated stainless steel tubing system complying with ANSI LC 1 fuel gas piping systems using CSST and listed with CSA, ICC and IAPMO. The FlashShield system is also listed to protective jacket standards, ICC-ES PMG LC1024 and LC1027. All mechanical tube fittings are SAE CA360 brass incorporating double wall flare sealing. The jacket-Lock and metal locking features provide steel tubing protection and continuous conductivity.

  • For flush mount fixed-point termination of appliances
  • Approved for concealed use
  • Tool-less flare fitting design
  • Metal to metal seal
  • Multi-point seal
  • Self-guiding fitting assembly
  • Jacket lock feature
  • Metal locking feature
  • 1-1/4 in hex nut
  • 1-1/8 in hex fitting
  • 5-3/16 in box size
  • 35 ft-lb assembly torque
  • Includes XR3 termination fitting, valve box, valve, finish plate, mounting brackets, jam nut and plug

Standards/Certifications: IAPMO C-3250 and 0239, ICC-ES PMG 1066/1155, ANSI Z21.15, ANSI/ASME B16.33, CSA 2728525 certified

Applications: For secure recessed termination point For connection to moveable appliances
