Potter 1808024
Send Print
  1. pin-int

Potter 1808024

PBA248 Red Powder Coated Steel Cover Powered Bell, 8 in, 24 VAC, 0.17 A, 94 dB at 10 ft, 2-11/16 in W

  • Manufacturers: Potter Electric Signal Company
  • Brand Name: Potter
  • PN: P1808024
  • MPN: 1808024
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Amperage Rating      :      0.17 A
Diameter      :      8 in
Dimension      :      2-11/16 in W
Finish      :      Red Powder Coated
Item Name      :      Powered Bell
Material      :      Steel Cover
Model      :      PBA248
Sound Level      :      94 dB at 10 ft
Temperature Rating      :      -40 to 150 deg F
Voltage Rating      :      24 VAC

These vibrating type bells are designed for use as fire, burglar or general signaling devices. They have low power consumption and high decibel ratings. The unit mounts on a standard 4 in (101mm) square electrical box for indoor use or on a model BBK-1 weather-proof backbox or BBX-1 deep weather-proof backbox for outdoor applications.

  • Outdoor use requires BBK-1 or HC-BB weather-proof back box
  • Indoor use mounts directly to standard 4 in box
  • Low-current draw
  • High dB output
  • AC and DC models
  • DC models are motor driven, polarized and have built-in transient protection for supervised alarm circuits
  • Non-corrosive composite material base

Standards/Certifications: UL, cUL listed, FM approved

Applications: For indoor and outdoor use

  • pdf Catalog https://www.plumbers-supply-co.com//ASSETS/DOCUMENTS/ITEMS/EN/UNI-PS21389_Cat.pdf
  • pdf Specification Sheet https://www.plumbers-supply-co.com//ASSETS/DOCUMENTS/ITEMS/EN/UNI-PS21389_Spec.pdf
