Victaulic VI717HR.212

FireLock Black Enamel-Painted Ductile Iron High-Pressure Check Valve with Grade T Nitrile Gasket, 2-1/2 in

  • Manufacturers: Victaulic
  • Brand Name: Victaulic
  • PN: VI717HR.212
  • MPN: VI717HR.212
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Connection Size      :      2-1/2 in
Dimension      :      13.81 in L x 9.37 in H
Disc Material      :      Stainless Steel
Finish      :      Black Enamel-Painted
Item Name      :      Check Valve with Grade "T" Nitrile Gasket
Material Specifications      :      ASTM A-536, Grade 65-45-12, ASTM A-395, Grade 65-45-15
Material      :      Ductile Iron
Model      :      717HR
Pressure Rating      :      365 psi
Seat Material      :      Electroless Nickel-Plated
Sub Brand      :      FireLock
Type      :      High-Pressure
  • Features a stainless steel disc which seats against the O-ring seal, when mounted on the electroless nickel-plated face
  • Machined surfaces electroless nickel-plated body seat
  • Grade "T" nitrile (orange color-code), temperature range -20 to 180 deg F
  • 300 series stainless steel disc
  • Brass shaft
  • Type 302/304 stainless spring
  • Type 416 stainless steel shaft plug
  • Zinc-plated carbon steel pipe plug

Standards/Certifications: cULus listed, FM approved

  • pdf Installation Sheet https://www.plumbers-supply-co.com//ASSETS/DOCUMENTS/ITEMS/EN/UNI-PS32068_Instal.pdf
  • pdf Specification Sheet https://www.plumbers-supply-co.com//ASSETS/DOCUMENTS/ITEMS/EN/UNI-PS32068_Spec.pdf
