Victaulic VI922.212.1G

FireLock, IGS Orange Enamel Ductile Iron Outlet Tee with 1 in Grooved Branch Outlet and Grade "E" EPDM Type-A Gasket

  • Manufacturers: Victaulic
  • Brand Name: Victaulic
  • PN: VI922.212.1G
  • MPN: VI922.212.1G
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Connection Size      :      2-1/2 x 1 in
Finish      :      Orange Enamel
Item Name      :      Outlet Tee with 1 in Grooved Branch Outlet and Grade "E" EPDM Type-A Gasket
Length      :      5-1/2 in
Material Specifications      :      ASTM A536, Grade 65-45-12
Material      :      Ductile Iron
Model      :      922
Pressure Rating      :      300 psi
Sub Brand      :      FireLock, IGS
  • Provides a direct branch connection at any location where a hole can be cut in the pipe.
  • Gasket - grade "E" EPDM (type-A) gasket (violet color code)
  • Carbon steel oval neck track bolts meeting the mechanical property requirements of ASTM A449 (imperial) and ISO 898-1 class 9.8 (metric)
  • Carbon steel hex flange nuts meeting the mechanical property requirements of ASTM A563 grade B (imperial - hex nuts) and ASTM A563M class 9 (metric - hex nuts)
  • Track bolts and hex flange nuts are zinc electro-plated per ASTM B633 FE/ZN5, finish type III (imperial) or type II (metric)

Standards/Certifications: cULus listed, FM, LPCB, VDS approved

Applications: For used to provides a convenient method of incorporating outlets For directly connecting sprinklers, drop nipples, sprigs, gauges, drains and other outlet products
