Delta Faucet 523LF-HDF

Chrome Brass 2-Handle Mid Arc Centerset Lavatory Faucet, 1.2 gpm at 60 psi, 3/8 in Compression, 4 in Centers

  • Manufacturers: Delta Faucet
  • Brand Name: Delta Faucet
  • PN: DE523LF-HDF
  • MPN: 523LF-HDF
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • 89 4.4 Branch Availability
Deck Thickness      :      2 in
Drain Type      :      Metal Grid Strainer
Faucet Center Size      :      4 in
Faucet Connection Size      :      3/8 in
Faucet Connection Type      :      Compression
Faucet Mount      :      Deck
Finish      :      Chrome
Flow Rate      :      1.2 gpm at 60 psi
Handle Type      :      Lever
Height      :      4-7/8 in
Item Name      :      Lavatory Faucet
Material      :      Brass
Number of Handles      :      2
Number of Holes      :      2 or 3
Spout Height      :      1-11/16 in
Spout Reach      :      5 in
Spout Type      :      Mid Arc
Type      :      Centerset
Valve Type      :      Ceramic Disc
  • Solid brass fabricated body
  • Vandal-resistant lever handle, red/blue colored graphics indicate hot/cold temperature
  • Diamond coated ceramic cartridge
  • Adjustable handle limit stop
  • 3/8 in OD copper supply tubes with 1/2-14 NPSM adapters
  • 1/4 in threaded mounting studs
  • Lifetime limited warranty
  • Verified compliant with 0.25% weighted average Pb content regulations

Standards/Certifications: ASME A112.18.1, A112.18.2, CSA B125.1, B125.2, ICC/ANSI A117.1, ADA complaint

  • pdf Installation Sheet https://www.plumbers-supply-co.com//ASSETS/DOCUMENTS/ITEMS/EN/UNI-PS8335_Instal.pdf
  • pdf Specification Sheet https://www.plumbers-supply-co.com//ASSETS/DOCUMENTS/ITEMS/EN/UNI-PS8335_Spec.pdf
